Placement machine Your location： Home > Equipment > Placement machine

产品简介

The turret placement head enables a single placement head to support the placement of multiple components. Full implementation of fast, versatile and high operating rates

Fastest 150,000CPH at the same level with 4 beams and 4 placement heads

Direct-drive placement head for high-speed, high-precision placement

SL Feeder (Super Loading Feeder) Opens up a New Era of Feeding Operations

Basic specifications

	Σ-F8S
Target substrate size	Monorail models:
	L330 x W250 ～ L50 x W50mm
	（Optional ： L381 x W510 ～ L50 x W50mm）
	Dual-track models：
	L330 x W250 ～ L50 x W50mm
Mounting capacity	High-speed placement head x 4 ：
	150,000CPH (Dual-track model)
	136,000CPH(Monorail model)
Placement accuracy In our best conditions (using standard components for evaluation)	High-speed placement head：
	03015 ： ±25μm（3σ）（140,000CPH）
	0402/0603 ： ±36μm（3σ）（150,000CPH）
Mounting head, mountable components	High-speed placement head：
	03015 CHIP ～ 4.3 x 3.4mm （T：2.0mm）
	High-speed universal placement head ：
	03015 CHIP ～ □33mm （T：12.7mm）
Number of feeders that can be installed	Up to 80 types (equivalent to 8mm tape)
Power Specifications	Three-phase: AC200V ± 10%, 50 / 60Hz
Gas supply	0.45 ～ 0.69MPa（4.6 ～ 7kgf/cm²）
Dimensions (except protrusions)	L 1,280 x W 2,240 x H 1,450mm(Excluding protrusions)
weight	about 1,940kg
